CYP Puma Ethernet or USB to HDMI Extender

Available: In Stock
Wishlist Compare
£593.99

Ethernet or USB to HDMI Extender

The PU-E4HX allows the user to display PC source content on 4 HDMI screens in an extended desktop mode via the extender's USB or Ethernet inputs. If a laptop is connected, the laptop screen content can be mirrored on HDMI output 1 of the Extender, and the desktop extended across the remaining 3 screens connected to the PU-E4HX outputs. Alternatively, the laptop screen can be extended so that the source image is stretched across all connected screens, ideal for use with PC driven digital signage content designed for configuration on up to four screens.

Features

  • Display content on up to 4 HDMI displays from a networked system or directly from PC/Laptop with USB cable
  • Supports HD resolutions up to 1920 x 1080 for each HDMI output
  • Individual EDID selection with output display control
  • USB 2.0 (Hi-speed) compliant
  • Support Gigabit Ethernet TCP/IP protocols
  • 3.5mm stereo jack inputs for embedding audio into the HDMI outputs
  • 16/32-bit color for high-quality images
  • Add four HDMI display to your computer through a USB 2.0 port
  • Share four HDMI displays with multiple users through an existing network within 100m
  • Individual output resolution on each HDMI output ports

Specification

Inputs 1x RJ45 [1x Ethernet Propriety Data] 1x USB Mini B [1x USB Propriety Data] 1x Stereo mini-jack [1x Analogue Stereo(L/R)]
Outputs 4x HDMI [4x HDMI Uncompressed AV and Data]
Power 5V/2.6A, DC (US/EU standards, CE/FCC/UL certified)
Dimensions 125mm (W) x 271mm (D) x 25mm (H)
Gross Weight 860g
Net. Weight 420g
