CYP Elector v1.3 HDMI® 4x2 Switcher

v1.3 HDMI 4 by 2 Switcher with Analogue Audio Routing The EL-42SA switcher from the Elector Range, is compatible to v1.3 HDMI specifications, supporting up to 12 bit Deep Colour together with High Definition audio. This switcher features additional analogue audio inputs for each of the four HDMI inputs. It has dual HDMI output which can be separately configured for audio routing, either internal (HDMI audio) or external (analogue stereo audio).

Features:

• v1.3 HDMI, HDCP 1.1, DVI 1.0 compliant.
• HDMI 4 Way Switcher with 2 Identical Outputs and audio routing.
• Resolutions Supported: PC - VGA, SVGA, XGA, SXGA, UXGA and WUXGA (1920x1200). HDTV 480i, 576i, 480p, 576p, 720p, 1080i, 1080p and 1080p24fps.
• High Definition Audio supported - Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio plus LPCM.
• Auto signal enhancement feature can improve signal quality after long distance transmission.
• RS232 and IR Remote Control. Supports 'Deep Colour' (10 and 12 bit).
• Additional analogue stereo audio inputs for routing to HDMI outputs.
• Dual HDMI outputs for simultanious connection to two HD Displays.
• Supports 3D signals.

Specification:

Inputs: 4 x HDMI, 8 x RCA (4 x Analogue Stereo)
Outputs: 2 x HDMI
Power: 5V/2.6A DC (US/EU standards, CE/FCC/UL certified)
Dimensions: 240mm (W) x 104mm (D) x 50mm (H)
Gross Weight: 900g
Net. Weight: 640g
