More and more devices are becoming SMART: TV, PVR, PC, laptop, tablet, phone, printers, games consoles –they all need to be connected, either to each other or to the internet.
Power Line Connection (PLC) is quick and simple and Sagemcom’s F@ST PLUG range utilises the electrical wiring around the house for a fast and reliable internet connection that will reduce buffering and maximise the connection speed.
Th FP502WIFI is the perfect solution to extend your wifi further around the house, to fill black spots of coverage or even expand out on to your patio or garden. Especially useful for mobile / hand held devices like you smartphone, tablet or laptop.
Simply locate your F@ST PLUG 502W where you want the additional coverage. The F@ST PLUG 502W also has 2 ports for ethernet connectivity.
**This is an expansion pack so a Sagemcom F@ST PLUG or other PLC device needs to be already in place.**
MAIN SPECIFICATIONS:
- PLC data transmission rate: 500Mbps*
- Wi-Fi data transmission rate : 300Mbps*
- 2 Ethernet Ports
- Quality of service management
- 128-bit AES Link Encryption with key management
- Power management
* Maximum throughput based on theoretical transmission PHY rate
POWER and CONSUMPTION:
Power : 100-240V AC 50-60Hz
Maximum consumption : TBC
Idle consumption : TBC
TEMPERATURE and ENVIRONMENT:
Operating Temperature: 0°C to 45°C
Max Relative Humidity (non condensing) : 90%
Wifi range : up to 300m in free field
PLC range inside building : up to 500m
APPLICATIONS:
- Broadband Internet network extension over Wi-Fi
- Connection of Smartphone or tablet anywhere in the house
- Streaming / Gaming over Wi-Fi or Ethernet
- IPTV, IP Camera over Wi-Fi or Ethernet
- Sharing files and devices over Wi-Fi or Ethernet
HARDWARE
Chipset AR7420 + Chipset AR9341
1 x Male Power Plug type E, E+F or type G
1 x Button ON/OFF switch
1 x Button Press Encryption with key management
1 x Button pairing Wi-Fi (short press) - Wi-Fi ON/OFF (long press)
1 x Button reset
1 x Power activity LED
1 x Powerline activity multicolor LED
1 x LED activity Wi-Fi
2 x LED activity Ethernet multicolore
2 x Ethernet Ports (Auto MDI/MDI-X)
1 x Configuration interface html onboard
Dimensions (mm) TBC
Weight : 183g
BOX CONTENT:
1 x F@ST PLUG 502W
1 x White Ethernet cable with RJ45 connectors
1 x Quick Start Guide
STANDARDS:
HomePlug AV
IEEE 1901
IEEE 802.11 b,g,n
