FRACARRO SWI85T15 1 way tap 15dB

The Fracarro SWI85T15 is dedicated for distribution of the satellite signals inside MSW systems.

Its composed of 4 IF 1-way taps and 1 Terrestrial 1-way tap in the same housing and can be used where you need to split trunk lines in two ways. It is compatible with the XS5 and XS5+ Fracarro Multiswitch Range.

It allows the DC to pass through all SAT line. It has F connectors that allow the DC powering through all SAT lines.
Small size, colour coded inputs/outputs and additional plastic bracket make the installation quick and easy.

Key Points

• 5 inputs ( 4SAT + 1 Ter ); 5 trunk + 5 tap outputs
• DC Pass on each SAT Lines
• Additional F connector for power injection on each SAT inputs/outputs
• Standard colour coded inputs/outputs for easy installation
• Plastic bracket for an easy installation
• HD Compatible

Satellite
Bandwidth MHz: 950–2150
Gain: -13
Insertion Loss dB: -2

Terrestrial
Bandwidth MHz: 5–862
Gain: -13
Insertion Loss dB: -2

General parameters
DC Pass (line): all
Dimensions mm: 155×105×25
Temperature Range °C -10 to +55
