Construction
Conductor: 20 (1)AWG, Solid Bare Copper
Insulation: Polyethylene
No of pairs: 2
Fillers: 2 x Cotton Rope
Overall Tape: Clear Polyester
Drain Wire: 27(7)AWG Tinned Copper
Overall Screen: Aluminium / Polyester Foil
Colour Code: Pair1: Red and Black, Pair2: White and Yellow
1st Jacket: Low Smoke Halogen Free, Green
2nd Jacket: Polyethylene, Black
Armour: Galvanised Steel
3rd Jacket: Polyethylene Black
Overall Diameter; 13 +/- 0.2mm
Working Voltage: 250v
Working Voltage (CE): 450v/750v
Test Voltage: 2.5Kv for 5 mins
Capacitance (Cond. to Cond.) 90 pF/m
Conductor Resistance: < 37.7ohm/km @ 20degC
Temperature Rating: 0 to 70degC
