Dragonsat DS-6000HD Free to Air Full HD 1080p DVB-S2 Satellite Receiver LAN USB
Dragonsat DS-6000HD is 3D ready and also supports full High Definition (HD), Full HD with 1080p and Dolby Digital to give you the best audio experience.
Dragonsat DS-6000HD Free to Air Full HD 1080p DVB-S2 Satellite Receiver LAN USB
Available:
In Stock
Wishlist
Compare
- Product SKU: 220/1007
- Category: Freesat / Satellite, PlutoDirect|Satellite & TV||PlutoDirect|Satellite & TV|Satellite Receivers|Satellite Box
£149.00
£199.00
Dragonsat DS-6000HD is 3D ready and also supports full High Definition (HD), Full HD with 1080p and Dolby Digital to give you the best audio experience.
- Full VFD Display
- Auto software update by Internet
- Auto Channal List by Internet
- Web Browsing
- Internet IPTV Support
- Internet Radio Support
- Weather Forecast
- YouTube Support
- Facebook Support
- CNN News
- Google Map
- Media Server
- Media Client
- Music
- Photo
- PVR
- Linux Based. (Supports FTP)
- 1W Standby
- Timeshift
- MKV Support
- External via 3G USB Modem Support
- External USB Wifi Support
Optional Plugins (Available Free of Charge)
| Main Features | ||
| * Digital Satellite receiver & PVR Ready | ||
| * H.264 / MPEG4 - HD,SD / DVB-S2 Compliant | ||
| * Recording & Playback with External USB 2.0 Devices | ||
| * Recording and Time Shifting Simultaneously | ||
| * Event Recording by EPG | ||
| * USB 2.0 Host ports (MP3 Player & JPEG Viewer) | ||
| * DivX file play back supported | ||
| * 10/100 Base Tx Ethernet port | ||
| * Fully compliant with DVB-S2 | ||
| * Blind scan | ||
| * Multi-LNB Controlled by DiSEqC Control Version 1.0, 1.1, 1.2 and USALS | ||
| * Multi-Satellite Search | ||
| * Support EPG (Electronic Program Guide) | ||
| * On-Screen Display with Full Color & Resolution | ||
| * Favorite Service Groups | ||
| * Powerful Service Control by Favorites, Lock, Skip, Move and Delete | ||
| * Service Sorting by Alphabet, Transponder and CAS | ||
| * Multi-language Supported ( OSD & Menu ) | ||
| * Teletext Support | ||
| * Maximum 10,000 Services Programmable | ||
| *PIP(Picture in Picture) | ||
| * Parental Lock / System Lock / Installation Lock | ||
| * CVBS Video & Audio Output via RCA | ||
| * HDMI Video & Audio Output | ||
| * Optical Output for Digital Audio(SPDIF) | ||
| * Software & Service Database update via USB and Ethernet port | ||
| Specifications | ||
| Tuner & Channel Decoder (Satellite) | ||
| Input Connector | F-type, IEC 169-24, Female | |
| Loop through out | F-type, IEC 169-24, Female | |
| Frequency Range | 950MHz ~ 2150MHz | |
| Input Impedance | 75Ω, unbalanced | |
| Signal Level | -65 to -25dBm | |
| LNB Power | 13/18VDC, max.400mA | |
| 22KHz Tone | (22±2)KHz, (0.6±0.2)V | |
| DISEqC Control | V1.0/1.2/USALS Compatible | |
| Demodulation | QPSK / 8PSK | |
| Input Symbol Rate | 2 ~ 67.5 Ms/s(QPSK of DVB-S) | |
| 2 ~ 52.5 Ms/s(8PSK of DVB-S2) | ||
| FEC Decoder | 1/2, 2/3, 3/4, 5/6 and 7/8 with Constraint Length K=7(DVB-S) | |
| 3/5, 2/3, 3/4, 4/5, 5/6, 8/9 and 9/10 (DVB-S2) | ||
| MPEG Transport Stream A/V Decoding | ||
| Transport Stream | H.264(MPEG-4 part 10, MPEG-4/AVC and H26L) | |
| MPEG-II ISO/IEC 13818-2/11172-2 | ||
| Profile Level | MPEG-4/AVC MP@L4, MPEG-II MP@HL> | |
| Input Rate | Max. 80Mbit/s | |
| Video Formats | 4:3 Letter Box, 4:3 PanScan, 16 : 9 | |
| Video Resolution | 720 x 576i, 720 x 576p, 720 x 480i, 720 x 480p | |
| 1280 x 720p, 1920 x 1080i, 1920 x 1080p(HDMI Only) | ||
| Audio Decoding | Dolby Digital, MPEG-1 Layer 1,2 and 3 | |
| Audio Mode | Streo/Joint stereo/Mono, Dolby AC-3 | |
| Sampling Rate | 32KHz, 44.1KHz and 48KHz(According to input) | |
| Main System | ||
| Main Processor | STi chipset | |
| Memory | Flash-ROM : 256 Mbytes | |
| SDRAM : 256 MBytes | ||
| EEPROM : 256 byte | ||
| Audio / Video & Data IN/OUT | ||
| RCA | CVBS Video Output, Audio L, R Output | |
| 1SCART | CVBS / Audio Output, RGB Output | |
| HDMI | Video & Audio Output | |
| OPTIC | AC-3 Dolby Digital (SPDIF) | |
| RS-232C | 9 pin D-SUB (Male) type, Transfer rate 115Kbps | |
| USB | 2*USB 2.0 Host Support (Front & Rear) | |
| ETHERNET | TX 10/100M Base | |
| Front Panel | ||
| Slot | 2 Common interface & 2 Smart Card Slot | |
| Display | VFD(Vacuum Fluorescent Display) - 8Digit | |
| Buttons | 3 Buttons(Standby, CH UP/DOWN) | |
| Indicators | 1LED(Standby) | |
| Power Supply | ||
| Input Voltage | AC 100 ~ 250V, 50/60Hz | |
| Type | SMPS | |
| Power Consumption | Max. 30W | |
| Protection | Separate Internal Fuse & Lighting protection | |
| Physical Specification | ||
| Size (W x H x D) | 260 × 55 × 205 | |
| Weight (Net) | 1.4 Kg | |
| Operating Temp. | 0°C ~ +45°C | |
| Storage Temp. | -10°C ~ +70°C | |
